16  Indicator LEDs and factory reset button

For location of the indicator LEDs and the factory reset button, see Figure 6.1 View from the rear .

16.1  Power/error indicator LED and factory reset button

Factory default level

Factory reset button depression time period

Indicator LED status

Explanation
Level 1
> 1 second
A continuous red light
When the factory reset button is released:
  • Default application measurements and settings are restored.
Level 2
> 4 seconds
A flashing red light
When the factory reset button is released:
  • Default application measurements and settings are restored.
  • Network default settings are restored.
Level 3
> 10 seconds
A rapidly flashing red light
When the factory reset button is released:
  • Default application measurements and settings are restored.
  • Network default settings are restored.
  • All changes to system configuration except installed software will be cleared.

16.2  Power/error indicator LED and power modes

Indicator LED status

Explanation
Flashing blue light
Normal operation.
Steady pink light
Camera is booting up.
Steady red light
Camera malfunction.

16.3  Wired Ethernet connection

Indicator LED status

Explanation
A flashing green light
The camera is connected to a network and the network activity is indicated.
No light (i.e., it is switched off).
The camera is not connected to any network.
